IPC-1910Plus 8K Network Tester Engineering Tool Coaxial Video Surveillance Tester AU Plug

1. 4 inch 800 x 480 full-view IPS capacitive touch screen + new interface, clearer, updated and smoother

2. H.265/H.265+, 8K main stream network camera test

3. Ultra-fast ONVIF, modify the IP address of the camera, customize the image channel name, etc.

4. AutoHD, automatically detect the type and resolution of the connected high-definition cameras

5. Upgrade to coaxial high-definition 4.0, TVI/CVI/AHD 8MP image test, TVI5.0 supports coaxial audio test for camera

6. Hikvision Dahua test tools support batch activation, batch modification of IP, and custom modification of channel names

7. Support resetting passwords for Hikvision cameras and setting video obstruction alarms

8. Network cable sequence detection, remote/middle/nearest error detection

9. DC12V 3A, POE 48V 25.5W power supply output

10. High brightness LED lighting

Parameters

1. External power supply: DC 12V (1A)

2. Battery power: built-in 7.4V / 2600mAh polymer lithium battery

3. Charging: charging time 3-4 hours. When the battery is fully charged, it can be used normally for about 9 hours.

4. Operation settings: capacitive touch screen. Multiple languages including simplified Chinese, traditional Chinese and English are available

5. Automatic standby: off / 5-30 minutes

6. Operating temperature: -10 degrees celsius to +50 degrees celsius

7. Operating humidity: percent 30 to percent 90

8. Size:about 16 x 10 x 4.5 cm

9. Weight: about 360g

Packaging list:

- IPC-1910 Plus x 1

- tool kit x 1

- BNC cable x 1

- charger x 1

- safety rope/wristband x 1

- power cord x 1

- RS485 control cable x 1

- audio test cable x 1

- cable tester x 1
